Kalista FR | 7W
SP 2440
Back to products
Namzo | 6W
SP 2102

Arlo | 35W
SP 9363

SP - 9363

Description

Adjustable recess LED down light with die cast aluminum in powder-coated, high power LED of long service life, providing multiple beam angle options, cold rolled steel deep cone and diffuser for anti-glare, excellent heat sink capability to minimize the luminous degradation, remote LED driver, SELV to be ordered separately. Tubular anti glare system placed inside the reflector. Complete with tempered safety glass.

Features

Wattage: 35W CCT: 2700K | 3000K | 4000K | 6000K CRI: > 90 Beam Angle : 15° | 25° | 38° | 60° Control: On/Off | DALI | TRIAC | 0-10V Ingress Protection: IP20 Lumen delivered up to 3,850 lm

Features

SKU SP - 9363 Categories ,
Wattage: 35W CCT: 2700K | 3000K | 4000K | 6000K CRI: > 90 Beam Angle : 15° | 25° | 38° | 60° Control: On/Off | DALI | TRIAC | 0-10V Ingress Protection: IP20 Lumen delivered up to 3,850 lm

Description

Adjustable recess LED down light with die cast aluminum in powder-coated, high power LED of long service life, providing multiple beam angle options, cold rolled steel deep cone and diffuser for anti-glare, excellent heat sink capability to minimize the luminous degradation, remote LED driver, SELV to be ordered separately. Tubular anti glare system placed inside the reflector. Complete with tempered safety glass.

SP9363_Arlo-02-01
*ALL DIMENSIONS ARE IN MILLI METER
  • Type    : Adjustable Recess LED Downlight
  • Use      : Indoor
  • Finish  : Matt Black, Matt White
  • Input   : 120 ~ 240 Vac - 50/60 Hz
  • Class  : |||

Download and resources

Instruction Manual
